Output voltage at 1000 Hz, 5cm/sec. | 0,4 mV |
Channel balance at 1 kHz | < 1 dB |
Channel separation at 1 kHz | > 24 dB |
Channel separation at 15 kHz | > 20 dB |
Frequency range at – 3dB | 20 – 55 kHz |
Frequency response 20 Hz – 20 kHz | +/-1,5 |
Tracking ability at 315Hz at recommended tracking force *) | 80 µm |
Compliance, dynamic, lateral | 12 µm/mN |
Stylus type | Nude Ortofon Replicant on conical alu cantilever |
Stylus tip radius | r/R 5/100 µm |
Tracking force range | 2,2-2,7 g (22-27 mN) |
Tracking force, recommended | 2,5 g (25 mN) |
Tracking angle | 23° |
Internal impedance, DC resistance | 5 Ohm |
Recommended load impedance | 50-200 Ohm |
Cartridge body material | Stainless steel / Aluminium |
Cartridge colour | Bronze/Black |
Cartridge weight | 10,7 gram |
